Bluetooth® Low Energy Module

Under Developement
Model Name : HY0021
HY0021

Features

  • Ultra-small module with slot antenna built into shielded package
  • Large area restrictions are not required. World's smallest occupied area on mounting board.(※1)
  • Easy for PCB design based on maximum patterning flexibility
  • Various certifications have been obtained.

product profile

  • Bluetooth v5.4 LE 2MPHY
  • Chip: Nordic nRF52805
  • CPU: Arm® Cortex®–M4
  • Memory: 192KB Flash / 24KB RAM
  • Integrated 32MHz, 32.768kHz clock
　　

Applications

  • Wearables
  • Health Care
  • Remote Control
  • IoT
  • Beacons
  • Computer Peripherals

Specifications

Bluetooth versionv5.4
Built-in Bluetooth ICNordic nRF52805
CPUArm Cortex–M4
Memory192KB Flash / 24KB RAM
Transmission power (dBm)+4 to -20 (4 dB step)
Sensitivity (dBm)-94 (1Mbps)
TX current (mA)7.0 (DC/DC, +4 dBm)
RX current (mA)4.6 (DC/DC, 1Mbps)
Number of GPIOs8
(SPI, I2C, UART, QDEC, ADC)
ADC12-bit 200ksps ADC (2ch)
High-speed clock (32MHz)Built-in
Low-speed clock (32.768kHz)Built-in
Operating Temperature range (°C)-40 to +85
Operating voltage range (V)1.7 to 3.6
Dimension (mm)3.5 x 10 x 1
Package24-Pin LGA
Certification/qualificationJapan (MIC)
U.S.A. (FCC)
Canada (ISED)
(ETSI EN300 328 V2.2.2)
Bluetooth
* Specifications are subject to change as the product is still under development.

Evaluation boards

Model Name : HY0023 　　　

Evaluation boards of FDK HY0021 is available. The boards may be used to check characteristics of the module and for software development.

Evaluation boards

Documents

Document NameVre.DateDownload File
Product Brief0.42024/9/30HY0021_ProductBrief_en.pdf
Datasheet---
Application Note---
EVB Manual---
  • ※1:As of Oct 21, 2024 According to our research.
  • FDK Corporation designs, manufactures and sells these modules under license of Slot Antenna on Shielded Package technology patented by Toshiba Corporation.
  • The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
  • Arm and Cortex are registered trademarks of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
